Chapter 2 Front Panel Operations RIGOL
DL3000 User’s Guide 2-107
Falling Slew Rate 0.001 A/μs
Trigger Source TRAN
List
Mode CC
Range 6 A
Circles 1
Steps 2
End State Off
Trigger Source TRAN
Step Value 2 A
Step Duration 1 s
Step Slew 0.001 A/μs
Battery
Current 0 A
Range 60 A
Cut-off Voltage OFF, 0 V
Battery Capacity OFF, 0 mAh
Discharge Time OFF, 0 s
Starting Voltage (Von) 0.5 V
OCP
Range 60 A
Starting Voltage (Von) 0.01 V
Delay Time 500 ms
Original Current 0 A
Step Current 1 A
Step Delay 500 ms
Protection Voltage 0.5 V
Maximum Current 10 A
Minimum Current 9 A
Protection Time 500 μs
OPP
Starting Voltage (Von) 0.01V
Delay Time 500 ms
Staring Power 0 W
Step Power 1 W
Step Delay 500 ms
Protection Voltage 0.5 V
Maximum Power 100 W
Minimum Power 90 W
Protection Time 500 μs
