(1) In the guide interface, press the Up/Down arrow key to switch the
parameter focus to "Delay_Step".
(2) Enter a value by using the numeric keys. For setting methods, refer to the
descriptions in "Parameter Setting Method".
Set OCP_V
The protection voltage in the OCP test mode. The default unit for the value is V.
(1) In the guide interface, press the Up/Down arrow key to switch the
parameter focus to "OCP_V".
(2) Enter a value by using the numeric keys. For setting methods, refer to the
descriptions in "Parameter Setting Method".
Set C_Max
The maximum value of the protection current in the OCP test mode. The default
unit for the value is A.
(1) In the guide interface, press the Up/Down arrow key to switch the
parameter focus to "C_Max".
(2) Enter a value by using the numeric keys. For setting methods, refer to the
descriptions in "Parameter Setting Method".
Set C_Min
The minimum value of the protection current in the OCP test mode. The default
unit for the value is A.
(1) In the guide interface, press the Up/Down arrow key to switch the
parameter focus to "C_Min".
(2) Enter a value by using the numeric keys. For setting methods, refer to the
descriptions in "Parameter Setting Method".
Set T_Limit
The maximum overcurrent protection time in OCP mode. If no action is
performed during the protection time, the load will automatically stop sinking
the current. The default unit for the value is
μs.
(1) In the guide interface, press the Up/Down arrow key to switch the
parameter focus to "T_Limit".
(2) Enter a value by using the numeric keys. For setting methods, refer to the
descriptions in "Parameter Setting Method".
4. Enter the main interface
In the guide interface, after you configure the parameters, press Apply to enter
the main interface, as shown in
Figure 2-30. At this time, "OCP" is active at the
top of the main interface, which indicates that the parameters have been
successfully configured. In the guide interface, if you give up configuring
parameters, you can press Cancel to exit the guide interface and enter the main
interface.
