RIGOL Chapter 2 Front Panel Operations
2-62 DL3000 User’s Guide
(1) In the main interface, press V_Stop to switch the parameter focus to
"V_Stop".
(2) Press V_Stop to switch to "ON", and select the cut-off voltage to be
the termination condition.
(3) Enter a value by using the numeric keys, arrow keys, or the knob. For
setting methods, refer to the descriptions of the help information or
refer to the descriptions in "Parameter Setting Method".
 If you do not need to set the cut-off voltage to be the termination condition:
(1) In the main interface, press V_Stop to switch the parameter focus to
"V_Stop".
(2) Press V_Stop to switch to "OFF", and the input box is disabled, and
you are unable to input any value.
Set C_Stop
When the battery capacity is set to the termination condition, after the battery
capacity reaches the set value, the load stops sinking automatically. The battery
stops discharging. The default unit is mAh.
 If you set the battery capacity to be the termination condition:
(1) In the main interface, press C_Stop to switch the parameter focus to
"C_Stop".
(2) Press C_Stop to switch to "ON", and select the battery capacity to be
the termination condition.
(3) Enter a value by using the numeric keys, arrow keys, or the knob. For
setting methods, refer to the descriptions of the help information or
refer to the descriptions in "Parameter Setting Method".
 If you do not need to set the battery capacity to be the termination
condition:
(1) In the main interface, press C_Stop to switch the parameter focus to
"C_Stop".
(2) Press C_Stop to switch to "OFF", and the input box is disabled, and
you are unable to input any value.
Set T_Stop
When the discharge time is set to the termination condition, after the discharge
time reaches the set value, the load stops sinking automatically. The battery
stops discharging. The default unit for the discharge time is s.
 If you set the discharge time to be the termination condition:
(1) In the main interface, press T_Stop to switch the parameter focus to
Tip
If the cut-off voltage is set to be the termination condition, when the battery
voltage is too low, the system will automatically discontinue test once it
confirms that the battery reaches the set value.
