Rigol DP800 Series Quick Guide

RIGOL
DP800 Quick Guide 15
Table 4 User Interface Explanation
No.
Explanation
1
Channel Number
2
Channel Output Voltage/Current
3
Channel Output State
4
Channel Output Mode
5
Status Bar, display the system status labels.
: over-temperature protection is enabled.
: the front panel is locked.
: the network is connected.
: the USB device is recognized.
: the beeper is enabled.
: the beeper is disabled.
: the instrument is working in remote mode.
6
Actual Output Voltage
7
Actual Output Current
8
Actual Output Power
9
Voltage and Current Setting Values
10
Overvoltage Protection and Overcurrent Protection Setting Values
11
Menu Bar
Tip
When the current display mode is “Normal” or “Waveform”, press at the front
panel to quickly switch between the current display mode and dial display mode.

Rigol DP800 Series Specifications

General

Brand	Rigol
Model	DP800 Series
Category	Power Supply
Language	English
