RIGOL Chapter 3 Performance Test
DS1000B Service Guide
3-14
16. Output a Sine with 1 MHz frequency and 1.2 Vpp amplitude via Fluke 9500B.
17. Repeat step 6.
18. Output a Sine with 20 MHz frequency and 1.2 Vpp amplitude via Fluke 9500B.
19. Repeat steps 8 to 10.
20. Output a Sine with 50 MHz frequency and 1.2 Vpp amplitude via Fluke 9500B.
21. Repeat steps 12 to 14.
22. Keep the other settings of the oscilloscope in step 3 unchanged and set the
vertical scale to 500 mV/div.
23. Output a Sine with 1 MHz frequency and 3 Vpp amplitude via Fluke 9500B.
24. Repeat step 6.
25. Output a Sine with 20 MHz frequency and 3 Vpp amplitude via Fluke 9500B.
26. Repeat steps 8 to 10.
27. Output a Sine with 50 MHz frequency and 3 Vpp amplitude via Fluke 9500B.
28. Repeat steps 12 to 14.
29. Turn off CH1. Repeat the steps above to test CH2, CH3 and CH4 and record the
test results.
Test Record Form:
Channel
Vertical
Scale
Test Result
Calculation Result Limit
Pass
/Fail
Vrms1
Vrms2
Vrms3
CH1
100
mV/div
Amplitude
Loss A1
[1]
-3 dB to 0
dB
Amplitude
Loss A2
[2]
≤-3 dB
200
mV/div
Amplitude
Loss A1
[1]
-3 dB to 0
dB
Amplitude
Loss A2
[2]
≤-3 dB
500
mV/div
Amplitude
Loss A1
[1]
-3 dB to 0
dB
Amplitude
Loss A2
[2]
≤-3 dB
CH2
100
mV/div
Amplitude
Loss A1
[1]
-3 dB to 0
dB
Amplitude
Loss A2
[2]
≤-3 dB
200
mV/div
Amplitude
Loss A1
[1]
-3 dB to 0
dB
Amplitude
Loss A2
[2]
≤-3 dB
500
mV/div
Amplitude
Loss A1
[1]
-3 dB to 0
dB
Amplitude
Loss A2
[2]
≤-3 dB
