RIGOL Chapter 3 Performance Test
DS1000B Service Guide
3-18
5) Rotate HORIZONTAL POSITION and VERTICAL POSITION
respectively to adjust the horizontal position and vertical position properly.
6) Rotate TRIGGER LEVEL to adjust the trigger level to the middle of the
screen.
5. Observe the screen of the oscilloscope. Press Cursor  Mode  “Manual” to
turn on the manual cursor function. Measure the zero point offset using manual
cursor measurement and record the measurement result.
6. Output a fast edge signal with 150 ps rise time and 3 V amplitude via Fluke
9500B.
7. Keep the other settings of the oscilloscope unchanged and set the vertical scale to
500 mV/div.
8. Repeat step 5. Measure the zero point offset and record the test result.
9. Turn off CH1. Repeat the steps above to test CH2, CH3 and CH4 and record the
test results.
Test Record Form:
Channel
Fast Edge Signal
Amplitude
Vertical
Scale
Test Result Limit
Pass
/Fail
CH1
1.2 Vpp
200 mV/div
≤ 0.5 div ×Minimum
Time Base Scale
[1]
3 Vpp
500 mV/div
CH2
1.2 Vpp
200 mV/div
3 Vpp
500 mV/div
CH3
1.2 Vpp
200 mV/div
3 Vpp
500 mV/div
CH4
1.2 Vpp
200 mV/div
3 Vpp
500 mV/div
Note
[1]
: For different models of oscilloscopes under test, the minimum time base scales are
different. For DS1204B, the minimum time base scale is 1 ns/div; for DS1104B, the minimum time
base scale is 2 ns/div; for DS1074B, the minimum time base scale is 5 ns/div.
