User’s Guide for DS1000E, DS1000D Series
6. After the Acquisition is set to “Averages” or Display Persistence is set
ON, the waveform refreshes slowly.
It is normal in these settings.
7. The signal is displayed as ladder like waveform.
(1) The time base setting maybe is too slow. Turn the horizontal knob to
increase horizontal resolution to improve the display.
(2) Maybe the display Type is set to “Vectors” set it to “Dots” mode to improve the
display.
