Rigol DS1000D series

RIGOL
© 2008 RIGOL Technologies, Inc.
User’s Guide for DS1000E, DS1000D Series
5-5
Trigger mode
D0~D15 select H, L, X, ,
Duration Trigger
[1]
Trigger Type
D0~D15 select H, L, X
Qualifier
＞, ＜, =
Time setup
20ns~10s
Measurements
Cursor
Manual
Voltage difference between cursors (∆V)
Time difference between cursors (∆T)
Reciprocal of ∆T in Hertz (1/∆T)
Track
Voltage value for Y-axis waveform
Time value for X-axis waveform
Auto
Cursors are visible for Automatic Measurement
Auto Measure
Vpp, Vamp, Vmax, Vmin, Vtop, Vbase, Vavg, Vrms, Overshoot,
Preshoot, Freq, Period, Rise Time, Fall Time, +Width, -Width,
+Duty, -Duty, Delay1→2 , Delay1→2
[1] For DS1000D Series;
[2] When sampling is 1GSa/s, only single channel can be used.
