Rigol DS1000D series User Manual

RIGOL
© 2008 RIGOL Technologies, Inc.
User’s Guide for DS1000E, DS1000D Series
V
General-Purpose Oscilloscopes
This book covers the following four types of DS1000E, DS1000D Series Digital
Oscilloscopes:
DS1102E, DS1052E,
DS1102D, DS1052D. (With Logic Analyzer)
RIGOL DS1000E, DS1000D Series Digital Oscilloscopes provide exceptional
waveform viewing and measurements in a compact, lightweight package. The
DS1000E, DS1000D series is ideal for production test, field service, research, design,
education and training applications involving analog/digital circuits test and
troubleshooting, as well as education and training.
Features of DS1000E, DS1000D Series:
 Dual Channel, Bandwidth:
100MHz (DS1102E, DS1102D)
50MHz (DS1052E, DS1052D)
 Optional 16 digital channels (DS1000D series), each channel can be turned on
or off independently, or in a 8 bit group
 Mono/Color TFT LCD Displays at 320× 234 resolution
 USB storage and printing supports, software upgradeable via USB connectivity
 Adjustable waveform intensity, more effective waveform viewing
 One-touch automatic setup for ease of use (AUTO)
 Saves 10 Waveforms, 10 setups, supports CSV and bitmap format
 Newly designed Delayed Scan Function, easy to give attention to both details
and overview of a waveform
 20 Automatic measurements
 Automatic cursor tracking measurements
 Waveform recorder, record and replay dynamic waveforms
 User selectable fast offset calibration
 Built-in FFT function, Frequency Counter
 Digital filters, includes LPF, HPF, BPF, BRF
 Pass/Fail Function, optically isolated Pass/Fail output
 Add, Subtract and Multiply Mathematic Functions
 Advanced trigger types include: Edge, Video, Pulse width, Slope, Alternative,

Rigol DS1000D series Specifications

General

Brand	Rigol
Model	DS1000D series
Category	Test Equipment
Language	English
