User’s Guide for DS1000E, DS1000D Series
Auto-set functions
After the AUTO is pressed the oscilloscope is configured to the following defaults:
Table 2- 91 The Auto menu
Menu Settings
Display format Y-T
Acquire mode Normal
Vertical coupling Adjust to AC or DC according to the signal.
Vertical position Adjust to right position
Vertical “V/div” Adjust to right scale
Volts/Div Coarse
Bandwidth limit Full
Signal Invert OFF
Horizontal position Center
Horizontal “S/div” Adjust to right scale
Trigger type Edge
Trigger source Find the channel with input signal automatically.
Trigger coupling DC
Trigger voltage Midpoint setting
Trigger mode Auto
RUN/STOP: Run or Stop waveform acquiring.
NOTE: The volts/div and horizontal time base can be adjusted in a fixed limit. That
is, to zoom in/out the signal in vertical and horizontal directions.
