Rigol DS1000E Series User Manual

RIGOL
© 2008 RIGOL Technologies, Inc.
User’s Guide for DS1000E, DS1000D Series
5-4
Acquisition Mode Average of ≥16 Waveforms with vertical position not at zero:
±[DC Gain Accuracy
×(reading+vertical position)+(1% of
vertical position) + 0.2div]
Add 2mV for settings from 2mV/div to 245 mV/div
Add 50mV for settings from 250mV/div to 10V/div
Delta Volts
Measurement
Accuracy (Average
Acquisition Mode)
Delta Volts between any two averages of 16 waveforms
acquired under same setup and ambient
conditions: ±(DC Gain Accuracy×reading + 0.05 div)
Trigger
Trigger Sensitivity 0.1div~1.0div (adjustable)
Trigger Level Range Internal ±6 divisions from center of screen
EXT ±1.2V
Trigger Level Accuracy
(typical) applicable for
the signal of rising
and falling time
≥20ns
Internal ±(0.3div × V/div)(±4 divisions from center of
screen)
EXT ±(6% of setting + 200 mV)
Trigger Offset
Normal mode: pre-trigger (memory depth/ 2*sample
rate), delayed trigger 1s
Slow Scan mode: pre-trigger 6div, delayed trigger 6div
Trigger Holdoff Range 500ns~1.5s
Set Level to 50%
(Typical)
When input signal frequency ≥50Hz
Edge Trigger
Edge Trigger
Slope
Rising, Falling, Rising + Falling
Pulse Width Trigger
Trigger Condition
(＞, ＜, =) positive pulse width, (＞, ＜, =) negative pulse
width
Pulse Width
Range
20ns ~10s
Video Trigger
Video Standard &
Line Frequency
Support for standard NTSC,
PAL and SECAM broadcast
systems. Line number range: 1~525 (NTSC) and 1~625
(PAL/SECAM)
Slope Trigger
