User’s Guide for DS1000E, DS1000D Series
1-15
Vertical offset back to 0 shortcut key
Turn the
knob to change the vertical display position of
channel and press the knob to set the vertical display position
back to 0 as a shortcut key
, this is especially helpful when the trace position is
far out of the screen and want it to get back to the screen center immediately.
2. Change the vertical setup and notice that each change affects the
status bar differently.
 View the status bar which is on the bottom of the screen to understand the
vertical scale.
 Change the vertical scale by turning the
knob and notice the change
in the status bar.
 Press CH1 , CH2 , MATH , REF , LA (only for DS1000D series) to display
the menu, sign, waveform of corresponding channel. Press OFF button to turn
off the channel.
Coarse/Fine Shortcut key
The Coarse/Fine vertical control can be set by simply
pressing the vertical
knob.
