User’s Guide for DS1000E, DS1000D Series
2-26
Set up Vertical Position and Scale
You can use the vertical controls to display waveforms, adjust vertical
and
, and set input parameters.
1. Using vertical
knob.
The vertical
control changes the position of signal waveforms in
all channels (including MATH and REF). The resolution changes according to the
vertical level set. Pressing this knob will clear the channel offset to zero. (The
function is available for DS1000D series, but not includes digital channel.)
2. Using vertical
knob.
The vertical
can change the vertical sensitivity of waveforms in all
channels (including MATH and REF, excluding LA). If the Volts/Div is set to
“Coarse”, the waveform scales in a 1-2-5 step sequence from 2 mV to 5 V. If the
Volts/Div is set to “Fine”, it scales to small steps between the coarse settings.
3. Channels can be adjusted by the vertical
and only when
they are selected.
4. During the vertical position, a position message is displayed on the left bottom
of the screen, in the same color as the corresponding channel. The unit is V
(Volts).
