RIGOL
© 2008 RIGOL Technologies, Inc.
User’s Guide for DS1000E, DS1000D Series
① ② ③
④ ⑤
Figure 2- 38
Status bar and mark for Horizontal control
Marks Indicator:
① The position of current waveform window in the memory
② The trigger position in the memory.
③ The trigger position in the current waveform windows.
④ The horizontal time base (main time base).
⑤ The trigger’s horizontal offset according to the center of the window.
