RIGOL
User’s Guide for DS1000B series
Auto mode
Press Cursor→Mode→Auto to display the manual mode menu.
Figure 2-143 Table 2-89 The Mode setting
Menu Settings Comments
Mode Auto
Display the cursors for
the current
automatic measuring. (See the following
figure).
There will be no cursor display if no parameters are chosen in Measure menu. The
oscilloscope could move cursor automatically to measure 22 parameters in Measure
menu.
Figure 2-144
Auto Measure Mode of Cursor Measurement
