Rigol DS1074B User Manual

RIGOL
User’s Guide for DS1000B Series
5-5
Time value for X-axis waveform
Auto Cursors are visible for Automatic
Measurement
Auto Measure Vpp, Vamp, Vmax, Vmin, Vtop, Vbase, Vavg, Vrms,
Overshoot, Preshoot, Freq, Period, Rise Time, Fall Time,
+Width, -Width, +Duty, -Duty, Delay A→B
, Delay A→
B
, Phase A→B ,Phase A→B
NOTE:
[1] Half channel indicates selecting one of the channels in CH1 and CH2, or in CH3 and CH4.
[2] This is the highest specification, the specific specifications are as follows:
DS1204B: 50GSa/s
DS1104B: 25GSa/s
DS1074B: 10GSa/s

Rigol DS1074B Specifications

General

Brand	Rigol
Model	DS1074B
Category	Test Equipment
Language	English
