Rigol DSA1030A series Accessories User Guide

RIGOL
DSA1000&DSA1000A Options&Accessories
13
USB-GPIB Interface Converter
By using RIGOL USB-GPIB interface converter, the spectrum analyzer could be
connected to a GPIB Bus Controller on PC. That is, the analyzer has been expanded
GPIB interface and could finish all sorts of work more easily through GPIB instructions.
And the main performance characters are shown below.
Connect the USB interface of the converter to the USB Host interface of the analyzer,
and connect the GPIB interface to the GPIB Bus Controller on PC.
 Enable GPIB control of the analyzer through the USB
Host port.
 GPIB primary address of the analyzer can be assigned
through the host instrument (PC).
 Powered by USB Host, do not need external power
supply.
 LED indicator provides the power status.
LED Indicator
Analyzer
PC
GPIB
USB
