RIGOL Chapter 2 Front Panel Operation
User’s Guide for DSA800/E Series
2-50
value of which will be displayed. RT Trace, MaxHold and 2FSK are mutually
exclusive.
3. MaxHold Rst
Delete the original signal and capture new signals for the max hold trace reset.
The reset operation has no effect on the user settings. You can also turn max
hold off and then turn it on to realizing the function of MaxHold Rst.
4. 2FSK
Enable or disable the 2FSK function. When the 2FSK function is enabled, the
user interface is divided into two areas automatically (the upper side is the
basic measurement window and displays the sweep trace; the lower side is
the measurement result display window). You can press Meas Setup to set
the related parameters. RT Trace, MaxHold and 2FSK are mutually exclusive.
Tip:
1. After the Sig Capture function is enabled, the instrument will automatically
set Span to 1.5 MHz. Pressing Preset to exit Sig Capture function can
restore the instrument to the default settings.
2. After the Sig Capture function is enabled,
 The Start Freq and Stop Freq menus under FREQ are grayed out and
disabled.
 All the menus under SPAN, BW/Det, Sweep/Trig, Trace/P/F,
Marker -> and Demod are grayed out and disabled.
 All the menus under System  Calibrate are grayed out and disabled.
 The Peak  Peak Table  State menu is grayed out and disabled.
 The Marker Fctn  Freq Count  State menu is grayed out and
disabled.
 If 2FSK is turned on, the Marker  Mkr Table  State menu is
grayed out and disabled.

The Sig Capture function and the advanced measurement functions are
mutually exclusive.
