Chapter 2 Front Panel Operation RIGOL
User’s Guide for DSA800/E Series
2-103
Preset
Recall the preset setting and restore the analyzer to a specified status.
Key Points:
 Press System  Reset  Preset Type to select “Factory” or one of “User1”
to “User6”.
 Press Preset to load the factory settings listed in the following table (except
items marked with “**”) or User-defined settings.
Table 2-62 Factory Settings
Parameter Default
Frequency
Center Freq 3.75 GHz
Start Freq 0 Hz
Stop Freq 7.5 GHz
CF Step Auto, 750 MHz
Signal Track Off
Span
Span 7.5 GHz
Amplitude
Ref Level 0 dBm
Ref Offset 0 dB
Scale/Div 10 dB
Input Atten Auto, 10 dB
Scale Type Log
Units dBm
RF Preamp Off
Input 50 Ω
MaxMixL -10 dBm
Corrections Off
BW/Det
BW
RBW Auto, 1 MHz
VBW Auto, 1 MHz
