Rigol DSA832 User Manual

Chapter 2 Front Panel Operation RIGOL
User’s Guide for DSA800/E Series
2-129
Browser
Press Storage  Browser to set browser type to “Dir” (directory) or “File”. You
can use the direction keys or the knob to select the desired disk or file.
 Dir: when selected, use the knob or direction keys to switch among C, D and E
(when a USB storage device is connected) disks.
 File: when selected, use the knob or direction keys to switch among files or
folders under the current directory. You can view at most 50 files under the
same folder.
Save
Save the file using the specified file type, file format and file source. Press this key
to enter the filename editing interface and refer to “To Input Filename
” to edit
the new filename. Note that the length of a filename is limited to 48 characters.
After finishing the filename editing, press Save to save the file to the directory
currently selected. Press Cancel to cancel the storage operation.
When storing a file in a USB storage device, if the filename is already in use, select
Cover file or Reenter.
 Cover file: press this key to replace the original file or folder.
 Reenter: press this key to return the filename input interface. You can reenter a
filename.
Expand Dir
Expand E disk or the folder currently selected in E disk when a USB storage device
is installed.
