Chapter 1 Quick Start RIGOL
User’s Guide for DSA800/E Series
Demod Set the demodulation function.
Marker
Read the amplitude, frequency and sweep time of a certain
point on the trace via marker.
Marker—>
Set other system parameters on the basis of the current
marker value.
Marker Fctn
Special functions of the marker such as noise marker, N dB
bandwidth measurement and frequency counter.
Peak
Open the peak search menu and search for peaks
immediately.
System Set the system parameters.
Print Setup Set the print parameters.
Storage Provide file storage and recall functions.
Auto Search for signals automatically within full frequency range.
User-defined shortcut key.
Restore the system to factory settings or user-defined state.
Print or save the current screen.
Help Turn on the built-in help.
Note:
*This function is only available for DSA815-TG/DSA832-TG/DSA875-TG/DSA832E-TG.
**This function is only available for DSA800/E with the corresponding option.
