Rigol MSO1074Z Manual

Chapter 1 Disassemble and Assemble RIGOL
MSO1000Z/DS1000Z Service Guide 1-3
Table 1-1 Part Explanation of MSO1000Z/DS1000Z Exploded View
No.
Part Name
No.
Part Name
○
1
Front Panel
○
16
Power Shield
○
2
Large Knob
○
17
Power Supply Board
○
3
Small Knob
○
18
Rear Foot
○
4
LCD
○
19
Rear Cover
○
5
Main Key PCB Board
○
20
Handle
○
6
Main Rubber Key
○
21
Handle Rotating Shaft
○
7
LCD Frame
○
22
Torx Countersunk Head Self
Tapping Screw PTF5*10
○
8
Torx Countersunk Head Screw
#FM4#-40*5/16
○
23
Power Socket
○
9
BNC Nut
○
24
Fan
○
10
Front Supporting Foot
○
25
Torx Pan Head Screw Assembly
M3*6
○
11
Front Metal Plate
○
26
Torx Pan Head Self Tapping
Screw M3*8
○
12
BNC Washer
○
27
PCB Board of the Keys at the Left
Side of the Screen
○
13
Torx Countersunk Head Screw
M3*6
○
28
Rubber Keys at the Left of the
Screen
○
14
Signal Source Output PCB
Board
○
29
Power Key
○
15
Main Board -- --
The recommended disassemble procedures are as follows:
To Disassemble the Rear Cover  To Disassemble the Rear Metal Cover  To
Disassemble the Knobs  To Disassemble the Front Panel  To Disassemble the
Keyboards, LCD and Digital Channel Input Port  To Disassemble the Main Board
