Preset
Recalls the preset setting and restores the system settings of the analyzer to a
specified status.
Remarks:
⚫ To set the preset type, press System → Preset → Preset Type to select
"Default" or any one of the items from "User1" to "User6".
⚫ Press Preset to recall the specified factory settings (as shown in the following
table, except the items specified in Note[3]) or user settings.
Parameter Name
GPSA Parameter
Value
RTSA Parameter Value
(RSA5000-B40)
Non-PvT
PvT
FREQ
Center Freq
3.25 GHz
3.25 GHz
Start Freq
0 Hz
3.23 GHz
Stop Freq
6.5 GHz
3.27 GHz
CF Step
Auto, 650 MHz
Auto, 4 MHz
Freq Offset
0 Hz
0 Hz
Signal Track
Off
--
SPAN
Span
6.5 GHz
40 MHz
Ref Value
--
--
0 us
Scale/Div
--
--
2.99885 ms
Ref Position
--
--
Left
Auto Scale
--
--
Auto
AMPT
Ref Level
0 dBm
0 dBm
Attenuation
Auto, 10 dB
Auto, 10 dB
RF Preamp
Off
Off
Y Axis Unit
dBm
dBm
Scale Type
Log
Log
Scale/Div
10 dB
10 dB
Max Mixer Lvl
-10 dBm
-10 dBm
Ref Offset
0 dB
0 dB
BW
RBW
Auto, 10 MHz
Auto, 197.64 kHz
(RBW2)
--
SPAN/RBW Ratio
Auto, 106
--
--
VBW
Auto, 10 MHz
--
--
VBW/RBW Ratio
Auto, 1
--
--
Filter Type
--
Gaussian
--
Sweep
