TECHNICAL DATA
Dimensions (mm) and weights (kg)
Height 860
Width 690
Depth of the corpus 545
Weight without casing 150
Weight with stone casing 180
Smoke flue outlet diameter 130
Nominal heating power DIN 18891 7 kW
Smallest thermal output 3,5 kW
Space heating capacity (m³) –
dependent on house insulation
70-190
Fuel flow 1,4 kg/h
Efficiency 79 %
CO2 content 10,9 %
CO emission rel. 13% O 1047 mg/Nm3
Dust emissions 33 mg/Nm3
Exhaust gas values for multiple use of the chimney
in accordance with DIN 4705, Part 3/chimney
dimensions to DIN 4705, Part 2
Exhaust gas mass flow g/s 8,6
Exhaust gas temperatur°C 289
Minimum delivery pressure at nominal
heating power Pa
12
