Spare part overview article numbers
# Art.Nr.: Description
1 B15245 heat protection compl.
2 Z31459 sensor clamp
3 B16521 Control panel
4 L00426 Flue plate
4*** L02585 Flue plate
5 B15782 container compl.
6 N111515 flame sensor
6*** B16114 Temperature sensor
*** B16053 sensor tube
*** L01441 Pressure bracket
7 N107887 fuse holder
8 N111586 safety temperature limiter
9 Z32147 ignition cartridge
10 B12301 screw
11 B15773 auger motor 220V/50Hz
11*** N111820 Screw motor, stepless
12 B15781 HP bracket
13 B15587 fan compl.
14** Z32344 combustion chamber door compl.
B15249
combustion chamber door compl. until Snr.
1301733
15 Z32340 door glas
16 Z34857 Locking bolt
L02220 lock tongue
B15313 door handle complete until Snr 1301733
N111576 Switch cabinet key
17 L00437 glass holder
18 B15244 combustion chamber lid compl.
18*** B16321 Combustion chamber cover metallic grey
18*** B16052 Combustion chamber cover black
19 N100485 Round sealing strip D12
20 N103693 culimeta flat packing black 8x2
21 Z30493 door handle chrome
22 Z35183 Sintered bearing Di10
23* Z35182 Plastic bearing
24 B16270 main board
24*** B15856 Motherboard C2 (for control panel)
25 N111825 door contact switch
26 N111597 capacitor
27 B16155 Induced draft fan housing
28 N111581 induced draught fan motor
29 N108315 O-ring D76/4.5
30 Z32422 cleaning opening metallic
31 N100055 hexagon socket screw
32 B15243 combustion chamber front compl.
33 B14478 Hinge BA1
34 N106591 cage nut electro-galvanised, cage NR M8
35 Z32345 fire trough
36 Z18502 pipe adapter
37 B15800 Cabletree
37*** Z34546 Cabletree
50 L01018 cover left compl.
51 B16020 convection fin compl.
52 L01021 container lid
53a L01016 rear wall top
53b L01025 rear wall bottom
*** LB00620 rear wall metallic
*** LB00621 rear wall black
54 L01017 cover right compl.
55 LB00441 casing right, cast grey
58 Z18278 air intake
59 Z32424 casing front/bottom, silver
# Art.Nr.: Description
62 Z35705 casing front/top silver
65 LB00442 casing left cpl., cast grey
L00797 motor plate
*** B16030 additional board
**
up to serial number 1301733 the firebox
door completely (B15249) must be supplied
as a spare part when replacing the firebox
door. In addition (111576) is required when a
Türtasuch the cabinet key.
*** from serial number 1328866
