ring Alarm Range Extender User Manual

Ring Alarm Range Extender User Manual
Date:
Version: 0.1
Page: 5
Ring Alarm Range Extender – Exclusion
Removing Ring Alarm Range Extender from a Z-Wave Network
Exclusion Instructions:
1. Initiate remove “Ring Alarm Range Extender” flow in the Ring Alarm mobile application – Select the settings icon from device
details page and choose Remove Device to remove the device. This will place the controller into Remove or “Z-Wave
Exclusion” mode.
2. Locate the pinhole reset button on the back of the device.
3. With the controller in Remove (Z-Wave Exclusion) mode, use a paper clip or similar object and tap the pinhole button. The
device’s red LED turns on solid to indicate the device was removed from the network.
Ring Alarm Range Extender – Factory Reset
Factory Default Instructions
1. To restore Ring Alarm Range Extender to factory default settings, locate the pinhole reset button on the device. This is found
on the back of the device after unplugging the device from the outlet.
2. Using a paperclip or similar object, insert it into the pinhole, press and hold the button down for 10 seconds.
3. The device will rapidly blink green continuously for 10 seconds. After about 10 seconds, when the green blinking stops,
release the button. The red LED will turn on solid to indicate the device was removed from the network.
Note: Use this procedure only in the event that the network primary controller is missing or otherwise inoperable.
Wake-Up Notification
Not applicable. Ring Alarm Range Extender is an Always On Slave (AOS) and does not support Wake Up Command Class.
Z-Wave Command Classes
Command Class
Version
Association
2
Association Group Information
3
Device Reset Locally
1
Firmware Update Meta Data
5
Indicator
3

ring Alarm Range Extender Specifications

General

Brand	ring
Model	Alarm Range Extender
Category	Extender
Language	English
