Charge Stage Indicator (RSC516 / RESC516 Only)
The ‘Charge stage indicator’ displays
the status of the charging process by
indicating the specific stage of the
charge cycle – An LED illuminates at
the relevant charge stage.
LED Light
All the SmartCharge range include an LED light.
The light is activated by pressing the LED light
switch.
No mains power is required to operate the
LED light
LED Battery replacement
The battery compartment is on the rear face of
the charger above the Charge station bracket – see
Rear view feature on page 5.
LED Battery specification
3.6v/200mAh Nickel-hydrogen non-rechargeable
button battery.
USB Charging Socket (RSC12, RESC12, RSC16 and RESC16 only)
1. Connect the SmartCharge AC mains power
lead to the AC mains power supply
2. Connect the USB charging lead of the
electronic appliance requiring charging to the
USB charging socket on the SmartCharge
3. When the appliance is fully charged disconnect
the USB charging lead from the USB charging
socket
The USB charging socket can also be operated
when the SmartCharge is charging a vehicle
battery.
The USB charging socket located on the front face of the SmartCharge allows the recharging of small
electronic appliances including MP3 players and mobile phones.
