Rinnai E- Series User Manual

18 008082013GW
Boiler has not been
burning but an
ionization flow
(flame) has been
detected.
NOTE: Inadvertently unplugging the ionization
cable or spark igniter wire while the boiler is
not firing can trigger the E00 code.
Check whether the ionization cable and/or the electrode
are responsible for a short circuit. Remove the plugs from
the ionization cable connected to the control unit and to
the electrode. Now using a ohm meter take a
measurement between the ionization connection and the
ground. Now refit it part by part until a short circuit takes
place.
WARNING: Turn off power and water supply to the boiler before removing or installing any parts.

Rinnai E- Series Specifications

General

Fuel Type	Natural Gas or Propane
Installation	Wall-mounted
Type	Condensing
Venting	Direct Vent
Dimensions	Varies by model
Weight	Varies by model
Warranty	12 years heat exchanger, 5 years parts
Heating Capacity	15, 000 - 199, 000 BTU/h
Vent Type	Direct Vent
