Rinnai Tankless Water Heater Installation and Operation Manual 67
7.4.1 REP199i/e Pressure Drop Curve (Water Heater + Pump)
7.4.2 REP160i/e Pressure Drop Curve (Water Heater + Pump)
Figure 98: Pump Flow Curve (199i/e)
Figure 99: Pump Flow Curve (160i/e)
MEDIUM
LOW
HIGH
MAX
MEDIUM
LOW
HIGH
MAX
