Rinnai REU-16 - Dip Switch Setting

22
Dip Switch Setting
Dip Switch Positions Explained
OFF ON
SW
1 - Gas Type LEGEND:
2 - Gas Type
Black Section indicates
3 - Computer Programming
position of dip switch.
4 - Computer Programming
5 - Computer Programming
OFF ON OFF ON
6 - Max. Temperature
7 - Combustion
OFF ON
8 - Combustion
Dip Switches Explained
GAS TYPE COMBUSTION
LPG NAT GAS NORMAL
OFF ON
SW
OFF ON
SW
OFF ON
SW
1 off 1 on 7 off
2 off 2 off 8 off
FORCED LOW
COMPUTER PROGRAMMING
OFF ON
SW
7 on
OFF ON
SW 8 off
1 Computer programming
2 Switches (3-5) must be left
FORCED HIGH
3 in the factory set position
4 for the Infinity 16i.
OFF ON
SW
5 7 on
6 8 on
7
8
MAXIMUM TEMPERATURE
OFF ON
4 Maximum Temperature = 60
0
C
4 Maximum Temperature = 75
0
C
