Ind. LuNAR RK200DTG3 Installation Guide 31
Tamper indication in the Relay or
BUS mode
Tamper probably
not closed
Visually verify that ceiling tamper and
spring are correctly installed
Walk test cannot be initiated via the
ProSYS keypad
Wrong code
Insert the appropriate code
Green LED doesn’t operate during
Walk test
-
MW channel does not
function
Ind. LuNAR
RK200DTG3
is
configured (via the
ProSYS) to the
“MW
disable on
DISARM”
during ProSYS’s
DISARM mode
Normal behavior
Ind. LuNAR
RK200DTG3
operating in
Bypass mode
due to “Bypass
MW channel
mode”
Reset the detector.
If MW channel trouble reoccurs, replace
the detector with a new one
Specifications
Coverage
Coverage pattern consists of 192 fingers (96 Fresnel facets) divided
into 3 lens sections.
Each lens section has 4 adjustable vertical positions for variable
mounting height and customized coverage.
360° by 18m (60ft) diameter. When moun
ting the detector under
3.7m, the coverage diameter starts to decrease up to 15m (50ft).
Variable Mounting Height
From 2.7m to 8.6m (9’ to 28’), 4 lens positions according to installation
height
RFI immunity
According to EN50130-4

Risco Industrial LuNAR RK200DTG3 Specifications

General

Microwave Frequency	10.525 GHz
Operating Voltage	9-16 VDC
Power Supply	12VDC
Tamper Protection	Yes
Type	Dual Technology Detector
Technology	Dual Technology
Detection Technology	Microwave, PIR
Operating Temperature	-10°C to +55°C (14°F to 131°F)
Humidity	95% max
Alarm Output	NC
