Temporary image adjustment method (manual adjustment) Item 21-3
[ Over lap of Head adjustment ]
This function is available on “HC5500 firmware Ver2.02” or later.
In addition, controller veision is required the following version or later.
HC3R-5000; Ver1.30 PS7R-9000; Ver3.30
[ Over lap of Head adjustment ]
Point
- Over-Lap is increased when input numerical value of minus.
- Input by 20䌾30 points. If input numerical value is small, change quantity is obscure.
- Perform SE mode 8-5-1-5-x (x: Head position)
- Adjustment for 4 drops is enough for normal papers
Adjust about faint line with 4 drop on and no line with 2 drop on
㩷㩷㩷㪪㫀㫑㪼㩷㪘㪊㩷
㪥㫆㩷㫃㫀㫅㪼
㪝㪸㫀㫅㫋㩷㫃㫀㫅㪼㩷
Clearly line
㪍㩷㪻㫉㫆㫇㩷
㪋㩷㪻㫉㫆㫇㩷
㪉㩷㪻㫉㫆㫇㩷
㪥㫆㩷㫃㫀㫅㪼
㪝㪸㫀㫅㫋㩷㫃㫀㫅㪼㩷
㪍㩷㪻㫉㫆㫇㩷
㪋㩷㪻㫉㫆㫇㩷
㪉㩷㪻㫉㫆㫇㩷
White line
Check here
