Operator's Manual
LOCKDOWN 2-MAN Ladder Stand
STEP 13
Ground
14
35
13
16
15
14. Ladder sections are assembled on the ground in
the following order: bottom ladder section (15),
ladder section with stabilizer bar mount (16),
middle ladders section (13) and the top ladder
section (14) with the treestand top assembly.
The ladder sections are secured together with the
six Silent LadderLocks with stud (35).
STEP 14
52
27
16
45
13. Attach the ladder ratchets (27) to the ladder
section with the stabilizer bar mount (16) using
two 1/4-20 x 2-1/4 IN bolts (45) and nuts (52). Set
aside for now.
