Operator's Manual
LOCKDOWN™ 21’ 360 1-MAN
STEP 9
9. Attach the curtain (28) to the shooting rail frame by centering the
zippered door with the top ladder section (11). With the curtain
draped over the shooting rail, connect the two sides with the
hook and loop. Note that the slits in the curtain should be in line
with the vertical shooting rail supports (24). SEE FIGURE 9A.
Starting with the two bottom buckles nearest to the door, wrap
each buckle strap around the platform and pull through the
platform mesh before securing. The curtain should be ush with
the bottom of the platform. SEE FIGURE 9B.
Once the bottom buckles are secured, wrap each top buckle
around the shooting rail and pull tight. SEE FIGURE 9C.
Once all buckles are secured, adjust the straps as necessary so
there are no gaps between the curtain and platform.
Once the stand is fully upright and secured to the tree, the
shooting rail and curtain can be adjusted to the user’s preference.
After adjusting the shooting rail to the proper height, pull the top
buckles until the curtain is tight. SEE FIGURE 9D.
FIGURE 9A
FIGURE 9B
FIGURE 9C
FIGURE 9D
ZIPPERED DOOR
SLIT
HOOK
AND LOOP
