(H) Chain Slap Guard (optional)
The chain slap guard is made to protect the lower frame
against dirt or scratches from the chain. It is placed on
the chain stay.
(I) Bottle Holder (optional)
Use the screws mounted on the frame tube seat to install the bottle holder.
(J) Hydraulic Brake Lever Adjustment (required tools: 2mm hex key)
1. Tighten the indicated bolt to extend the brake lever reach.
2. Loosen the indicated bolt to shorten the brake lever reach.
(K) Removing The Battery
The battery keys are attached to the handlebar. Insert the key into
the key port, turn clockwise, and pull the battery or battery lever.
Failure to carry out proper assembly, operation, and/or !
maintenance could result in serious injury or death."
