RJM Rack Gizmo User Manual

9
Setup Examples
The following diagrams show some of the many ways you can use your Rack Gizmo in a guitar rig. Please check our web site for more examples.
INOUTINOUTINOUTINOUTINOUTINOUTINOUTINOUT
RJM Music Technology, Inc. www.rjmmusic.com
Rack Gizmo Wiring Diagram
Rack Gizmo Wiring Diagram 4 pedals in front of the amp, 4 pedals in the amp’s loop, tuner The guitar signal passes from the front panel jack, through the buer, then through the rst 4 audio loops, through the Click Stopper circuit and into the amp’s input. The last four loops are inserted into the amp’s eects loop. These can be either pedals or rack units, but be sure to make sure the signal levels match between eects and the amp. The Rack Gizmo controls channel switching on the amp using one of the function switching jacks.
Guitar connects to front panel input
From MIDI Controller Out
To Tuner
Footswitch Jack
Input
Amp
Return LOOP Send
