RJM Rack Gizmo User Manual

13
INOUTINOUTINOUTINOUT
RJM Music Technology, Inc. www.rjmmusic.com
Rack Gizmo Wiring Diagram
Rack Gizmo Wiring Diagram 6 pedals, preamp, 2 stereo eects processors in parallel, stereo power amp The guitar signal passes from the front panel jack, through the buer, through 6 audio loops and the Click Stopper, then goes to the preamp. The stereo preamp output signal is sent to two stereo eects processors in audio loops 7 and 8, mixed in parallel with the dry signal, then sent to a stereo power amp. Note: Dashed lines indicate stereo (TRS) connections.
Guitar connects to front panel input
INOUTINOUT
IN 1 IN 2 IN 3 IN 4 (dry)
Mini Line
Mixer
Out
Output Input
InputOutput
Stereo FX 2
Stereo FX 1 MIDI Thru
MIDI In
MIDI In
From MIDI Controller Out
Preamp
Input
Output
Power Amp
Stereo Input

RJM Rack Gizmo Specifications

General

Brand	RJM
Model	Rack Gizmo
Category	Switch
Language	English
