RJM Rack Gizmo User Manual

25
MIDI Implementation Chart v 2.0 (Page 2 of 3)
Manufacturer: RJM Music Technology, Inc. Model: Rack Gizmo Version: 1 Date: August 3, 2011
Control #
Function
Transmitted (Y/N)
Recognized (Y/N)
Remarks
0
Bank Select (MSB)
N
Y
Banks 0 and 1 only
1
Modulation Wheel (MSB)
N
N
2
Breath Controller (MSB)
N
N
3
N
N
4
Foot Controller (MSB)
N
N
5
Portamento Time (MSB)
N
N
6
Data Entry (MSB)
N
N
7
Channel Volume (MSB)
N
N
8
Balance (MSB)
N
N
9
N
N
10
Pan (MSB)
N
N
11
Expression (MSB)
N
N
12
Effect Control 1 (MSB)
N
N
13
Effect Control 2 (MSB)
N
N
14
N
N
15
N
N
16
General Purpose Controller 1 (MSB)
N
N
17
General Purpose Controller 2 (MSB)
N
N
18
General Purpose Controller 3 (MSB)
N
N
19
General Purpose Controller 4 (MSB)
N
N
20
N
N
21
N
N
22
N
N
23
N
N
24
N
N
25
N
N
26
N
N
27
N
N
28
N
N
29
N
N
30
N
N
31
N
N
32
Bank Select (LSB)
N
N
Use CC#0 instead
33
Modulation Wheel (LSB)
N
N
34
Breath Controller (LSB)
N
N
35
N
N
36
Foot Controller (LSB)
N
N
37
Portamento Time (LSB)
N
N
38
Data Entry (LSB)
N
N
39
Channel Volume (LSB)
N
N
40
Balance (LSB)
N
N
41
N
N
42
Pan (LSB)
N
N
43
Expression (LSB)
N
N
44
Effect Control 1 (LSB)
N
N
45
Effect Control 2 (LSB)
N
N
46
N
N
47
N
N
48
General Purpose Controller 1 (LSB)
N
N
49
General Purpose Controller 2 (LSB)
N
N
50
General Purpose Controller 3 (LSB)
N
N
51
General Purpose Controller 4 (LSB)
N
N
52
N
Y
53
N
Y
54
N
Y
55
N
Y
56
N
Y
Alt. CC Range 2
57
N
Y
Alt. CC Range 2
58
N
Y
Alt. CC Range 2
59
N
Y
Alt. CC Range 2
60
N
Y
Alt. CC Range 2
61
N
Y
Alt. CC Range 2
62
N
Y
Alt. CC Range 2
63
N
Y
Alt. CC Range 2
