RJM Rack Gizmo User Manual

26
MIDI Implementation Chart v 2.0 (Page 3 of 3)
Manufacturer: RJM Music Technology, Inc. Model: Rack Gizmo Version: 1 Date: August 3, 2011
Control #
Function
Transmitted (Y/N)
Recognized (Y/N)
Remarks
64
Sustain Pedal
N
Y
Alt. CC Range 1
65
Portamento On/Off
N
Y
Alt. CC Range 1
66
Sostenuto
N
Y
Alt. CC Range 1
67
Soft Pedal
N
Y
Alt. CC Range 1
68
Legato Footswitch
N
Y
Alt. CC Range 1
69
Hold 2
N
Y
Alt. CC Range 1
70
Sound Controller 1 (default: Sound Variation)
N
Y
Alt. CC Range 1
71
Sound Controller 2 (default: Timbre / Harmonic Quality)
N
Y
Alt. CC Range 1
72
Sound Controller 3 (default: Release Time)
N
N
73
Sound Controller 4 (default: Attack Time)
N
N
74
Sound Controller 5 (default: Brightness)
N
N
75
Sound Controller 6 (GM2 default: Decay Time)
N
N
76
Sound Controller 7 (GM2 default: Vibrato Rate)
N
N
77
Sound Controller 8 (GM2 default: Vibrato Depth)
N
N
78
Sound Controller 9 (GM2 default: Vibrato Delay)
N
N
79
Sound Controller 10 (GM2 default: Undefined)
N
N
80
General Purpose Controller 5
N
Y
Audio Loop 1
81
General Purpose Controller 6
N
Y
Audio Loop 2
82
General Purpose Controller 7
N
Y
Audio Loop 3
83
General Purpose Controller 8
N
Y
Audio Loop 4
84
Portamento Control
N
Y
Audio Loop 5
85
N
Y
Audio Loop 6
86
N
Y
Audio Loop 7
87
N
Y
Audio Loop 8
88
N
Y
Function Switch 1
89
N
Y
Function Switch 2
90
N
Y
Function Switch 3
91
Effects 1 Depth (default: Reverb Send)
N
Y
Function Switch 4
92
Effects 2 Depth (default: Tremolo Depth)
N
Y
Function Switch 5
93
Effects 3 Depth (default: Chorus Send)
N
Y
Function Switch 6
94
Effects 4 Depth (default: Celeste [Detune] Depth)
N
Y
Function Switch 7
95
Effects 5 Depth (default: Phaser Depth)
N
Y
Function Switch 8
96
Data Increment
N
N
97
Data Decrement
N
N
98
Non-Registered Parameter Number (LSB)
N
N
99
Non-Registered Parameter Number(MSB)
N
N
100
Registered Parameter Number (LSB)
N
N
101
Registered Parameter Number(MSB)
N
N
102
N
N
103
N
N
104
N
N
105
N
N
106
N
N
107
N
N
108
N
N
109
N
N
110
N
N
111
N
N
112
N
N
113
N
N
114
N
N
115
N
N
116
N
N
117
N
N
118
N
N
119
N
N
120
All Sound Off
N
N
121
Reset All Controllers
N
N
122
Local Control On/Off
N
N
123
All Notes Off
N
N
124
Omni Mode Off
N
N
125
Omni Mode On
N
N
126
Poly Mode Off
N
N
127
Poly Mode On
N
N
