Configure Channel Settings Menu • 39
10.Press the UP/YES button to save the configuration. The screen will
then return to the Channel Control & Setup menu.
11. Press ESCAPE to return to the screen which asks Control & Setup
Program Proceed? [YES] or [NO].
12.{Press the DOWN/NO button to return to normal operation.
Table 9: Channel Setting Parameters
Parameter
(Factory-Set Value)
Description
ALARM-1 Level
See the Beacon 200 Detector Head
Specification Sheet for the detector
head installed on this channel
The gas reading at which the Beacon 200 initiates an alarm 1 condition
for this channel.
ALARM-1 ON DELAY
(1 sec)
The amount of time the Beacon 200 delays activation of the alarm 1
circuit once an alarm 1 condition is initiated.
ALARM-1 OFF DELAY
(0 sec)
The amount of time the Beacon 200 delays turning off the alarm 1 circuit
once an alarm 1 condition passes.
ALARM-1 (activation)
(DECREASING for oxygen channels,
INCREASING for all other channel
types)
Indicates if the alarm 1 circuit is activated by gas readings INCREASING
or DECREASING to the ALARM-1 Level.
ALARM-1 Relay (action)
(NORMALLY DE-ENERGIZED)
If set as NORMALLY DE-ENERGIZED, the channel’s alarm 1 relay is de-
energized in normal operation and energizes when an alarm 1 condition
is initiated.
If set as NORMALLY ENERGIZED, the channel’s alarm 1 relay is
energized in normal operation and de-energizes when an alarm 1
condition is initiated.
ALARM-1 Relay (reset)
(SELF RESETTING for oxygen,
LATCHING for all other channel types)
If set as LATCHING, you must press the RESET button to reset the
alarm 1 circuit after the alarm 1 condition passes.
If set as SELF RESETTING, the Beacon 200 automatically resets the
alarm 1 circuit after the alarm 1 condition passes.
ALARM-2 Relay (used for)
(ALARM-2 Condition)
If set as ALARM-2 Condition, the channel’s alarm 2 relay activates
when an alarm 2 condition is initiated for the channel.
If set as FAIL Condition, the channel’s alarm 2 relay activates when a
fail condition is initiated for the channel.
ALARM-2 Level
See the Beacon 200 Detector Head
Specification Sheet for the detector
head installed on this channel
The gas reading at which the Beacon 200 initiates an alarm 2 condition
for this channel.
ALARM-2 ON DELAY
(2 min for oxygen, 1 sec for all other
channel types)
The amount of time the Beacon 200 delays activation of the alarm 2
circuit once an alarm 2 condition is initiated.
ALARM-2 OFF DELAY
(0 sec)
The amount of time the Beacon 200 delays turning off the alarm 2 circuit
once an alarm 2 condition passes.
To Next Page
