RM Cylinders Intercyl - Fault Finding: Tundish Issues

ISSUE 2016 Rev 1 - Installation Manual
3
RM Cylinders
TUNDISH - FAULT FINDING
Is water running from
the Tundish?
Is the water
being discharged hot?
Tundish
YES
NO
Do you have
pressure?
YES
NO
No fault.
See the flow chart for
T&P Valve.
See the flow chart for
Inlet Control Group.
Check Temperature &
Pressure Relief Valve.
Check Safety Relief Valve.
