RM Cylinders Intercyl - Fault Finding: Temperature & Pressure Valve

ISSUE 2016 Rev 1 - Installation Manual
3
RM Cylinders
T & P VALVE - FAULT FINDING
Is warm/hot water running
from the Tundish?
Fault Fixed?
Temperature & Pressure
Relief Valve.
YES
NO
Do you have
pressure?
YES
NO
No fault
with the T&P.
No fault
with the T&P.
Replace T&P if
required.
Replace T&P if
required.
Check temperature setting
of the cylinder stat.
Reduce stat temperature
or reset Limit Switch.
Check Cold Inlet Pressure
Relief Valve
Check T&P Valve cap
for tightness/dirt.
