4
English
TURNTABLE OPERATION
1. Select “PHONO” mode by pressing the [MODE] button (2) repeatedly;
2. Place a record on the turntable. Place the EP adapter over the central spindle
when playing 45 rpm records;
3. Set the [SPEED SELECTOR] (33) to 33, 45 or 78 rpm according to the record;
4. Release the tonearm clamp, and remove the stylus protector;
5. Lift up the [TONEARM] (34) with the [LIFT LEVER] (31);
6. Move the [TONEARM] (34) to the beginning of the record;
7. Lift down the [TONEARM] (34) with the [LIFT LEVER] (31);
8. When the record is finished the plate will automatically stop turning. To stop ma-
nually, lift up the tonearm from the record and return it to the rest support.
Note: Do not stop or turn the plate manually.
When the unit is moved or transported:
Lock the [TONEARM] (34) with the tonearm clamp.
Place the protective cap on the stylus (even when not in use).
RADIO OPERATION
1. Select “TUNER” mode by pressing the [MODE] button (2) repeatedly;
2. Press the [SKIP -/+] buttons (10/11) to manually select the frequence or press
and hold (2 seconds) to scan the next/previous available station.
Note: For a better reception reorient the antenna (29).
STORE RADIO STATIONS AUTOMATICALLY:
Press the [SCAN] button (15) and the radio will automatically scan the radio. During
the scanning process, the radio will save the scanned stations sequentially into the
memory.
PRESET
There are 30 presets available for FM.
1. Set the desired radio station frequency as explained previously;
2. Press the [PRESET] button (16);
3. Choose the number of preset using the [PRESET -/+] buttons (12/13);
4. Confirm with the [PRESET] button (16).
Press the [PRESET -/+] buttons (12/13) to recall a preset station.
