Technical Specification
Weight and Dimensions are approximate. Because we continually strive to
improve our products we may change specifications and designs without prior
notice.
Installation instruction
Selection of installation equipment
Cut out the work surface according to the sizes shown in the drawing.
For the purpose of installation and use, a minimum of 5 cm space shall be
preserved around the hole.
Be sure the thickness of the work surface is at least 30mm. Please select
heat-resistant work surface material to avoid larger deformation caused by the
heat radiation from the hotplate. As shown below:
L(mm)
W(mm)
H(mm)
D(mm)
A(mm)
B(mm)
X(mm)
750
430
62 58
695
410
50 mini
Cooking Zones
2 zones
Supply Voltage
220-240V~/50-60Hz
Total Power 4200-5300W
Product Size L×W×H(mm)
750X430X62
Built-in Size A×B (mm)
695X410
