Product Overview
Dear Users:
Thank for your buying our gas hob. Please read this operation manual carefully before
installation or operation of this product. Meanwhile, please keep it properly for future
reference.
ROBAM specializes in kitchen appliances, for example, range hood, gas hob, etc.
ROBAM gas hob adopts advanced technology, fashion design, optimistic structure,
high heat efficiency and safe operation, too.
Structure
(This picture is only for your reference. There are series of models, we don’t list all of
them one by one)
Item Name
Item No.
Gas Style
Rated Pressure
Heating Load(kW)
Gas Connector
Product Size(mm)
Net Weight(kg)
Air in flow
Installation Size(mm)
Panel
lgnition Method
Built-in Gas Hob
JZ(Y/T)-B928 JZ(Y/T)-G980
φ9.5mm special gas rubber gasket(G1/2 inch special metal gasket)
760×440 160×
14 12
2
Full
Tempered Glass
Stainless Steel
703×403 R15×
Pulse
See the label
See the label
See the label
760×450 162×
Parameters
Note:
1.Parameters indicate for reference only. The exact datas should be confirmed on the
label on the gas hob;
2.The installation size of built-in gas hob should be confirmed by the specification on
the templet in the carton;
3.We keep right to alter design or specification;
1.Fashionable design: The design of model and structure comply with fashion and
adapt to modern kitchen.
2.Excellent quality: Top quality of accessories with trustable quality, long life
expectancy;
3.Electronic pulse with flame failure safety device on each burner and high thermal
efficiency.
4.Full air in flow: Built-in structure with full air in flow , cooktop supplyment air, air valve
adjust flexibly, burn completely and easy to install;
Product Feature
Pan stand(flat)
Copper core
Copper cover
Copper base
Electrode needle
Thermocouple
Burner
Panel
Underpan
Feet
Switch
Pan stand (round)
Gas Burner
Gas Hob Gas Hob
1 2
