SPECIFICATIONS continued
Key to Drawing Dimensions:
Dimension
3 Litre
5 Litre
7.5 Litre
10 Litre
15 Litre
25 Litre
40 Litre
A mm
283
334
334
334
490
490
490
B mm
143
176
176
176
180
235
325
C mm
400
430
515
615
615
615
615
D mm
234
267
267
267
271
326
416
E mm
15
15
15
15
8
8
8
F mm
50
50
50
50
32
32
32
G mm
53
53
53
53
103
103
103
H mm
18
18
18
18
32
32
32
N mm
212
245
245
245
249
304
394
M mm
142
167
167
167
245
245
245
Specifications:
Size (L)
3
5
7.5
10
15
25
40
Approx. Weight – Empty (Kg)
6
8
9
10
15
17
19
Approx. Weight – Full (Kg)
10
15
19
22
34
47
67
Min Water Pressure (kPa)
50
50
50
50
75
75
100
Max Water Pressure (kPa)
1000
1000
1000
1000
1000
1000
1000
Element Power (kW)
1.8
2.4
2.4
2.4
2.4
3.6
4.6
Table 3: Dimension Specification
