OPERATING INSTRUCTIONS

ROBATHERM AUTOFILL BOILING WATER UNIT

Models

AR3, AR5, AR7, AR10,

AR15,AR25, AR40

Version 1

These instructions cover the models of Robatherm

Boiling Water Units listed above, Although

there are slight variances between models, the installation, operation, care and maintenance

procedure is the same for all.

Table of Contents

Questions and Answers:

P
Patricia ThomasJul 31, 2025
What to do if robatherm AR3 does not fill with water?
- K
  Kyle DavisJul 31, 2025
  If your robatherm Boiler isn't filling with water, several factors could be at play. First, ensure there is an electrical supply and the unit is properly plugged in. Then, verify that the water supply is active. A blocked inlet strainer could also be the cause; inspect it and clean or replace if necessary. Other potential issues include an electronic controller failure (test it), a solenoid valve failure (check its resistance and replace if broken), or a blocked filter (if your unit has one, check and replace it, referring to section 5E for resetting).
S
Stacey NealAug 15, 2025
Why robatherm AR3 Boiler fills water to low level and does not heat?
- D
  deannaleeAug 15, 2025
  If your robatherm Boiler fills water to a low level but doesn't heat, the thermal cut-out may have tripped and needs resetting. Another possibility is a heating element failure; if properly wired, check its resistance and replace it if broken. An electronic controller failure could also be the cause, so test it. Finally, a thermistor failure could be the reason; consider replacing the thermistor.
