Figure 1: Mounting Dimension Specification
WATER SUPPLY CONNECTION
Cold mains pressure water (refer to specification table for minimum water
pressures) must be piped and connected to the ½” BSP inlet fitting located on the
left hand side underneath the unit. An accessible isolating valve must be installed
near the unit.
This unit contains an inlet strainer on the water inlet connection (refer to figure 1).
To ensure continuing satisfactory operation, it is suggested that the inlet strainer be
serviced every six months by a qualified service person. Where poor water quality
is present it is recommended to install an additional auxiliary filter.
