About
The SWT16+ is a 16-track Eurorack step sequencer with up to 64 steps
per track. The module makes it possible to create up to 8 dierent patterns
which can stored in a total of 16 presets. Programmable like a classic TR
machine, the SWT16 can be used not only for triggering drum sounds but
also envelopes or other modulation sources. This manual gives an over-
view of the many ways in which the sequencer can create and inuence
rhythms.
Installation
The SWT16 requires a ±12V power supply (2x5-pin connector). The red
strip of the ribbon cable (-12V side) must be oriented on the same side as
the «Red Stripe» mark on the board. The module draws about 70mA from
the +12V rail.
Rock
BD SD CH OH
Disco
BD SD CH OH
Hip Hop
BD SD & CP CH CB
Bossa Nova
BD CH TB CL
Funk
BD SD CH OH
Lambada
BD RS CH OH
