- 3 -
MAINTENANCE
CHANGING THE BLADE
Use Roberts #10-910 (9"), 10-940 (13”)
or 10-990 (18”) Replacement Blade. Use
the provided Allen wrench to remove
the screws, then hold the blade at each
end and carefully move the blade out of
blade holder.
Note: The flat side of the blade should
face the table.
Warning: Do not put your fingers against
the sharp edge of the blade at any time.
CHANGING THE NYLON BAR
Use the provided Allan wrench to
remove the screws, then hold the nylon
bar and carefully move it out of nylon
bar holder.
Warning: Do not put your fingers against
the sharp edge of the blade at any time.
TRANSPORT
Insert the pin as shown to the hole in the
aluminum eccentric cam and carry the
cutter as shown.
